Millennium 3 Essential CB20 12I/8O R - 12 On/Off Inputs with 6 Analog, 8 Static Relay Outputs (4 PWM) - 24VDC Power Supply - Green Display - Industrial Automation & Control System for Manufacturing & Smart Home Applications
Millennium 3 Essential CB20 12I/8O R - 12 On/Off Inputs with 6 Analog, 8 Static Relay Outputs (4 PWM) - 24VDC Power Supply - Green Display - Industrial Automation & Control System for Manufacturing & Smart Home Applications

Millennium 3 Essential CB20 12I/8O R - 12 On/Off Inputs with 6 Analog, 8 Static Relay Outputs (4 PWM) - 24VDC Power Supply - Green Display - Industrial Automation & Control System for Manufacturing & Smart Home Applications

$284.88 $517.97 -45%

Free shipping on all orders over $50

7-15 days international

23 people viewing this product right now!

30-day free returns

Secure checkout

98301596

Guranteed safe checkout
amex
paypal
discover
mastercard
visa
apple pay

DESCRIPTION

Crouzet 88974031, Millenium 3 Essential CB20-12I/8O R, 12 x On/Off inputs, Incl 6 analogue inputs, 8 x Static relay outputs incl 4 x PWM output, 24 VDC Supply, Green Display

  • Highly visible blue LCD with 4 lines of 18 characters and configurable backlighting
  • More cost effective solution
  • Allow the use of the entire library of specific functions blocs of the software workshop
  • Extended temperature range (-20 °C →+70 °C)
  • Analogue inputs 0-10 VDC, Potentiometer, NTC, LDR (0-20 mA/Pt100 with converters)
  • Open to XN network communication extensions, digital I/O, analogue, Pt100 extensions
  • HMI Screens Available
    Specification
    Crouzet Part Number88974031 (CB20-12I/8O R)
    Analogue Inputs0-10VDC (x6)
    Digital Inputs12/24VDC (4.4mA @ 12VDC) (x16)
    Digital OutputsRelay, 5-30VDC,24-250VAC @ 10mA minimum (x10)
    PWM SSR Output12-24VDC @ 500mA (x4)
    ExpandableYes
    LCD DisplayNone
    Mounting StyleDIN Rail Mount (124.6mm)
    Supply Voltage Range24VDC (21.6 - 28.8VDC)
    Termination StyleScrew
    Weight350g
    CertificationCE, UL, CSA, GL
    Factory Pack Qty1
    Over Voltage Category3 in accordance with IEC/EN 60664-1
    Pollution Degree2 in accordance with IEC/EN 61131-2
    Protection ratingIP40 (Front), IP20 (Rear)
    Mechanical Resistance

    Immunity to vibrations IEC/EN 60068-2-6, test Fc

    Immunity to shock IEC/EN 60068-2-27, test Ea

    Resistance to HF InterferenceImmunity to radiated electrostatic fields IEC/EN 61000-4-3 Immunity to fast transients (burst immunity) IEC/EN 61000-4-4, level 3 Immunity to shock waves IEC/EN 61000-4-5 Radio frequency in common mode IEC/EN 61000-4-6, level 3 Voltage dips and breaks (AC) IEC/EN 61000-4-11 Immunity to damped oscillatory waves IEC/EN 61000-4-12
    Conducted and radiated emissionsClass B (*) in accordance with EN 55022, EN 55011 (CISPR22, CISPR11) group 1 (*) Except configuration (88 970 1.1 or 88 970 1.2) + (88 970 250 or 88 970 270) + 88 970 241 class A (class B in a metal enclosure)
    Operating Temperature-20 →+70 °C except CB and XB versions in VDC : -30 →+70 °C (+40 °C in a non-ventilated enclosure) in accordance with IEC/EN 60068-2-1 and IEC/EN 60068-22


    Datasheet
    Software
