12.5kvar 525V 50Hz 3 Phase Power Factor Correction Capacitor - 3 x 48.1uF Gas Filled with Internal Discharge Resistors (75 x 230mm) - Ideal for Industrial Equipment, HVAC Systems and Electrical Power Distribution

$102.3 $186 -45%

Free shipping on all orders over $50

7-15 days international

16 people viewing this product right now!

30-day free returns

Secure checkout

85228237

Guranteed safe checkout

Electronicon 275.546-604800/221K02, 12.5kvar 525V 50Hz, Power Factor Correction Capacitor, 3 Phase, 75 x 230(+32 +5/-2)mm Gas Filled, 3 x 48.1uF, Internal Discharge Resistors

Low losses metallized self-healing polypropylene film, high density, high temperature and greater dielectric resistance Volt/µ
Aluminium case with bottom fixing M12x16

Electronicon Part Number	275.546-604800/221K02
Technology	Gas Filled, Low Loss, Self Healing
Dimensions	75 x 230(+32)mm
Standards	IEC 60831-1/2, EN 60831-1/2
Voltage	525V @ 50Hz
Kvar	12.5 Kvar
Capacitance	3 x 48.1uF
Tolerance On Capacitance	-5% + 10% (others on request)
Current (In)	3 x 13.7 Amp
Overpressure Disconnection System	YES
Self Extinguishing Resin	YES
Internal Fuses	YES
Self Healing	YES
Mounting	M12 x 16mm (Indoor)
Operating Temperature Range	50°C Max, 30°C Mean(1 year), 40°C Mean(24 hrs)
Lifetime	120,000 Hours
Termination Style	Filter Type Terminal
Approvals	UL 810, CSA C22.2 No.90
Unit Weight	1.6kg
Factory Pack Quantity	30
